HT813
Hybrid ATA with FXS and FXO Ports
The HT813 is an analog telephone adapter that features 1 analog telephone FXS port and 1 PSTN line FXO port.
- Supports 2 SIP profiles through 1 FXS port and 1 FXO port
- Dual 100Mbps LAN and WAN ports
- Lifeline support (FXS port will be hard-relayed to FXO port) in case of power outage
- 3-way voice conferencing per port
- Automated & secure provisioning options using TR069
- Supports T.38 Fax for reliable Fax-over-IP
- Failover SIP server automatically switches to secondary server if main server loses connection
- Strong AES encryption with security certificate per unit
Grandstream Device Management System
GDMS provides a FREE centralized interface to provision, manage, monitor and troubleshoot Grandstream products, including device management, account management, device configuration, firmware upgrades, device monitoring, intelligent alarm, and statistical analysis, individually or in batches of devices by site, group and model. This powerful cloud management platform adds robust security features to protect enterprise networks, including bank-grade TLS encryption from end-to-end, two-factor login authentication to protect your data security, two-way certificate verification and encryption of all device information. By offering a centralized, secure and zero-touch management for Grandstream endpoints, GDMS is ideal for enterprises, service providers and multi-site businesses as it allows them to easily deploy and manage large networks of Grandstream solutions. Visit gdms.cloud to sign up for free today!
Android and iOS mobile users can access the GDMS mobile app from any device by downloading for free through the app store, or get it on google play.
Product Comparison
NameHT813 |
---|
SPECS |
LINES 2 lines |
AUDIO CONFERENCING 3-Way Voice Conferencing Per Port |
TELEPHONE INTERFACES One (1) RJ11 FXS port, One (1) RJ11 FXO PSTN line port with lifeline support |
NETWORK INTERFACES Two (2) 10/100Mbps ports (RJ45) with integrated NAT router |
LED INDICATORS POWER, LAN, WAN, FXS, FXO |
TELEPHONY FEATURES Caller ID display or block, call waiting, flash, blind or attended transfer, forward, hold, do not disturb, 3-way conference |
FAX OVER IP T.38 compliant Group 3 Fax Relay up to 14.4kpbs and auto-switch to G.711 for Fax Pass-through |
